General Specifications

Maximum Audio Power - 180W

RMS Power - 90W

HDMI Video Inputs - 1

HDMI Video Output(with Audio Return Channel) - 1

HDMI HDCP Version - 2.2

Bluetooth version - 4.2

Weight - 9.5 lb (4.3 kg)

Power Supply - 100-240V~50/60Hz

Wi-Fi network compatibility - IEEE 802.11b/g/n/ac (2.4G/5G)

Bluetooth Profile - A2DP v1.3/AVRCP v1.5

Bluetooth Frequency Range - 2402MHz-2480MHz

Bluetooth Max Transmitting power - 9 dBm (EIRP)

Bluetooth Transmitter modulation - GFSK, π/4 DQPSK, 8DPSK

2.4G Wi-Fi Frequency Range - 2412 – 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)

2.4G Max Transmitting power - 18 dBm (EIRP)

2.4G Wi-Fi modulation - OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM

5G Wi-Fi maximum transmitter power - 18dBm (EIRP)

5G Wi-Fi modulationOFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM, 256QAM

5G Wi-Fi transmitter frequency range - 5.150~5.350GHz, 5.470~5.725GHz, 5.725~5.825GHz

2.4G short-range wireless frequency range - 2402 – 2478MHz

2.4G short-range wireless maximum transmitter power - 0dBm (EIRP)

2.4G short-range wireless modulation - π/4 DQPSK

Power Consumption - 33 W

Standby Power Consumption - <2W

Packaging Weight (Gross) - 13.4 lb (6.1 kg)

Audio Specifications

Frequency Response - 76Hz-20kHz

Audio inputs - 1 Analog, 1 Optical, Bluetooth, USB, Wi-Fi

Audio Channels - 8

Max SPL - 98dB SPL

Total Harmonic Distortion (THD) - 1%

Operating temperature - 0°C - 45°C

Dimensions

Packaging Dimensions (W x H x D) - 37" x 7.5" x 7" (940mm x 190mm x 180mm)

Dimensions(W x H x D) - 33.8" x 2.6" x 4.9" (860 x 65 x 125mm)

Woofer Size - 6 x 2" (50mm)

Tweeter Size - 2 x 1" (25mm)
